SMD 3030 UV 365nm led
SMD chip UV led, 3030 is the special size. Dongguan Zhiding Electronics Technology Co., Ltd is led manufacturer in China, professionally provide design, production and manufacture of LEDs and LED components.
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is ±0.10mm (0.004') unless otherwise specified.
Features :
● Chip Material: InGaN
● Lens Color: Water Clear
● Emitted Color: UV 365-420nm
● 3.0×3.0×0.6mm (3030) standard package.
● Suitable for all SMT assembly methods.
● Compatible with infrared and vapor phase reflow solder process.
● Compatible with automatic placement equipment.
Below is data sheet for 0.5W type (150mA), 3030 SMD LED also have 1W type.
| Product Name | SMD 3030 UV LED 365nm | Product Model | AL-H30EMU36-ELIK-W1 |
| Power Dissipation | 0.5W | Light Color | UV |
| Forward Voltage | 3.2-4.2V | Viewing Angle | 120° |
| Forward Current | 150mA | Operating Temperature | -40 - 80℃ |
| Radiant Flux | 100-300mW | Storage Temperature | -40 - 100℃ |
| Wavelength | 365nm | Soldering Temperature | 260℃ |
Notes:
1. Tolerance of Luminous Intensity ±15%
2. Tolerance of Forward Voltage ±0.1V
UV LED Series:
UV Wavelength Range: 270nm, 275nm, 280nm, 365-420nm
Molding Encapsulation Technology
High Purity Ceramic Base
Imported UV resistant silica gel
High quality UV Chip
High Radiation Power
60°, 120°Beam Angle for 3535 5050 UV Series
High power 1-3W UV LED
Application Scenario
UV LED 365-420nm are widely used for currency Detector, Fluorescence Detection, 3D Priting, Ink Curing, Exposure, LED Plant Grow & Aquarium Lights, Biological Detection, LED Mosquito-lured Lamp and so on.
Our Advantages:
1. Best raw materials from domestic and foreign well-known brand manufactures.
2. Strict testing before shipping.
3. Best logistics services for all shipments.
4. 3 years warranty for all products
FAQ
Q1. Can I have a sample order?
A: Sample order is welcomed to test and check quality. Mixed samples are welcomed as well.
Q2. What about the lead time?
A: 3-7 working days for sample, 10-15 working days for bulky order based on the quantity.
Q3. How about MOQ?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-7 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order?
A. Please tell us your requirements or application.
B. Quotation or solution will be sent to you accordingly.
C. Sample will be shipped to you after everything is confirmed
D. Modify or confirm the order according to your opinion.
E. Start the production after your confirmation of order.
Q6: Do you provide OEM service?
A: Yes. OEM is welcomed .
Q7: Do you offer guarantee for the products?
A: Yes, 3 years warranty.
For SMD 3030 UV led, we welcome samples order to test order. We will provide professional technical guidance and support on LED.
