Advanced Facilities Efficient Production
Dongguan Zhiding Electronics Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of uv c led 3535 in China, also supports customized service. If you're going to wholesale advanced uv c led 3535 made in China, welcome to get quotation from our factory. Also, 2 years warranty is available.
UV C LED 3535
SMD 3535 UVC LED 100mA type 7-10mW output, with a competitive price.
PART NO.: AL-H35GAU27-E6IA-P9
Features :
1. Chip Material: InGaN
2. Lens Color: Water Clear
3. Lens Material: Au plating on Cu Substrate
4. Emitting Color: UV
5. Pb free.
6. The product itself will remain within RoHS compliant version.
Package Dimensions
Notes:
1. All dimensions are in mm.
2. Tolerance is ±0.25mm unless otherwise noted.
Technical data sheet:
Absolute Maximum Ratings at Ta=25 °C:
| Parameter | Symbol | Maximum | Unit |
| Power Dissipation | Pd | 0.8 | W |
Peak Forward Current (Duty 1/10 400msec Pulse Width) | IFP | 200 | mA |
| Forward Current | IF | 100 | mA |
| Thermal Resistance, Junction-Case | Rth, J-C1 | 15 | °C/W |
| Electrostatic Discharge (HBM) | ESD | 4000 | V |
| LED Junction Temperature | TJ | 125 | °C |
| Operating Temperature Range | Topr | -30°C to +60°C | |
| Storage Temperature Range | Tstg | -30°C to + 100°C | |
| Lead Soldering Temperature[2.0mm from body] | Tsol | Reflow Soldering : 175 °C for 10 sec. | |
Electrical and Optical Characteristics:
| Parameter | Symbol | Test Condition | Min. | Typ. | Max. | Unit |
| Radiated Flux | Φe | IF=100mA | 7 | 10 | - | mW |
| Radiant Irradiance | Ee | IF=100mA | - | 2.0 | - | mW/cm2 |
| Peak Wavelength | Λp | IF=100mA | 270 | 275 | 280 | nm |
| Spectrum Line Halfwidth | Δλ | IF=100mA | - | 11 | - | nm |
| Forward Voltage | VF | IF=100mA | 5.5 | 6.5 | 7.9 | V |
| Viewing Angle | 2θ1/2 | IF=100mA | - | 120 | - | Deg |
| Reverse Current | IR | V R=5V | - | - | 50 | uA |
Note: 1. Forward voltage measurement allowance is ± 0.2V.
2. Radiant flux measurement allowance is ± 10%.
3. Irradiance tested at a distance 10mm from Al reflector.
4. Wavelength measurement allowance is ± 3nm.
Relative Spectral distribution
I-V Characteristic
Radiated power VS current
Usage Notice:
It is recommend to use low temperature solder paste for reflow, and the temperature curve is shown in the following diagram.
Applications:
1.Curing
2.Sterilization
3.Medical, nail dryer
4.Currency Verification, currency detector
5.Fluorescence Microscopy
6.Inspection of dyes, rodent and animal contamination
7.Leak detection
Shipping:
1.FedEx/DHL/UPS/TNT for samples, Door-to-Door
2. By Air or by Sea for batch goods, for FCL; Airport Port receiving
3 Customers specifying freight forwarders or negotiable shipping methods
4.Delivery Time. 3-7 days for samples; 5-25 days for batch goods
In the absence of inventory, we will arrange production as soon as possible according to customer needs. Providing quality service to customers is the basic premise of our Sales. Welcome to inquire about our products!
For UV sterilizer, water purification and disinfection and other medical application, 275nm SMD 3535 UVC led is your best choice!
